Inductive sensor NBN3-F31K2M-Z8L-B33-S

Inductive sensor NBN3-F31K2M-Z8L-B33-S

• Direct mounting on standard actuators
• Compatible with all process control systems
• 2 solenoid valves can be connected
• Weatherproof housing for outdoor applications
• Rugged metal base
• Temperature range -40 ... 167 °F (-40°C to 75°C)
• 2-wire DC sensor with minimum off-state current
• LEDs for switching state of sensor and solenoid valve
• Plug-in terminals
• Connection (valve side) : 4-pin, M12 x 1 socket
• Tightening torque, housing screws : ≤ 2 Nm
• Tightening torque, cable gland : M20 x 1.5 ; max. 11 Nm - M12 x 1 max. 3 Nm
• Tightening torque, stopping plug : 1 Nm
• Tightening torque : Male connector , 1 Nm
